12V2A UL FCC approved power adapter with LED lingt indicator
Input Characteristics:
1.Voltage :100-240VAC ± 10%;
2.Frequency: 50/60Hz;
3.Current: 0.6A Max;
4.Starting Time: 3s Max;
5.Inrush Current: 30A/240VAC Max;
Output characteristics:
1.constant current / constant voltage mode;
2.high precision, low noise;
3.Hold up time: 20mS Min;
Protection:
• short circuit protection
• over current protection
• over voltage protection
• thermal shutdown protection
Application:
DVD players, LCD and TFT TVs, MP4 players, digital cameras, CCTV ,other A/V products,cell phone charger,network information,security equipment,small home appliances,etc.
Certifications:
UL,cUL,CCC,CE,CB,GS,FCC,EK,SAA,C-tick, CSA,PSE,S-MARK.
We can supply verious kinds of adaptor to meet your requirements.
Features:
- Ultra-small size, light weight,
- fully sealed and easy to carry;
- Cooling mode: natural cooling;
- Safety standards: IEC/EN/UL60950/UL60335;
- Average failure rate: 50,000 hours;
Environmental:
- Operating temperature: 0 °C -40 °C, 5% -90% RH;
- Storage temperature: -20 °C -85 °C, 5% -95% RH;
Electrical characteristics:
| Model | I/P Condition | Output(V) | Output(A) | Output(W)max |
| SK02G-XXXXYYYW | | 2.8-6.0V | 0.10-3.00A | 18W |
| SK02G-XXXXYYYW | 100- | 6.1-8.9V | 0.10-3.00A | 24W |
| SK02G-XXXXYYYW | 240VAC | 9.0-11.9V | 0.10-2.67A | 24W |
| SK02G-XXXXYYYW | 0.6A Max | 12.0-14.9V | 0.10-2.00A | 24W |
| SK02G-XXXXYYYW | 50/60Hz | 15.0V-18.9V | 0.10-1.60A | 24W |
| SK02G-XXXXYYYW | | 19.0-24.0V | 0.10-1.27A | 24W |
Certificates:
About us:
Simsukianis a professional AC DC Adapter manufacturer with over 18 years experience. our products have passed CE, CB, GS, ERP, ROHS, PSE, KC, SAA, C-Tick, MEPS, UL, FCC, CEC, CCC etc. safety approbation and we can apply for other safety approbation for you if necessary. Cooperated with some big brands such as FLEXTRONICS,SKYWORTH,KONKA,FOXCONN,etc.
If you are interesting in our power adapters, feel free to contact me.
We are looking for to cooperating with you in the near future
|
|
